OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 33 of 131 H60301-3e-ID-B.doc
SCAN-DATA
selects the data types to be send in the Scan Mode.
Bit: 7 6 5 4 3 2 1 0
Function Byte
Order
COM-
Prefix
0 0 0 0 DB UID
Notes:
• If the bits UID and DB are set to 0, the scan-mode is switched off.
UID = Serial No.
Setting of this bit activates the output of the UID
b0 Output of the UID inactive
b1 Output of the UID active
DB = Data Block
Setting of this bit activates the output of a specified data field.
b0 Output of a data field inactive
b1 Output of a data field active
COM Prefix
When this option is on, the Reader will transmit the COM-ADR before each data set.
b0 COM-ADR of the Reader will not transmit
b1 COM-ADR of the Reader will transmit
Byte Order
Defines the Byte Order within frame
b0 MSB first
b1 LSB first
Note:
If the COM Prefix is enabled the COM-ADR will be send in front of the Header
