GRN / RED / BUZZER (PRH: BLUE instead of RED)
Bit Combination Signal device
b00 unchanged
b01 on
b10 off
b11 flashing
Startup Buzzer / LED (only idle state)
When this option is selected, the Reader will switch the BUZZER and the LEDs on
for two seconds to indicate that the Reader is ready after the Reader is supplied with
power. If the Reader is reset by software, only both LEDs switch on for 2 seconds.
IDLE-FLASH / ACTIV-FLASH:
By means of the two bytes "IDLE-FLASH" and "ACTIV-FLASH" the signal transmitter may be pro-
vided with a flashing frequency for idle and active position.
Bit: 7 6 5 4 3 2 1 0
Function: 0 0 BUZZER RED GRN
Bit combination flashing frequency
b11
b10
b01
b00
1 Hz
2 Hz
4 Hz
8 Hz
ACTIV-xxx-TIME
If a Transponder was detected, the transmitter and the duration can be set by the bytes ACTIV-STATE
and ACTIV-FLASH. Each signal transmitter (LED, BUZZER) may be activated temporarily limited.
Signal transmitter
time range
ACTIV-GRN-TIME
0...255 x 100 ms
ACTIV-RED-TIME
0...255 x 100 ms
ACTIV-BUZZER-TIME
0...255 x 100 ms
