OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 52 of 131 H60301-3e-ID-B.doc
MODE:
Via the Parameter MODE different information could requested from the Reader.
0x00: General hard- and firmware information's of the reader firmware
0x02: General hard- and firmware information's of the USB-Controller firmware
0x80: Device-ID
This Information's are necessary for some firmware updates or firmware upgrades.
SW-REV:
Revision status of the firmware. Depending on the Mode and reader type different controller’s
are meant.
D-REV / HW-TYPE / SW-TYPE / TR-TYPE:
see: 5.4. [0x65] Get Software Version
RX-BUF:
RX-BUF is the maximum receive buffer size of the Reader. If a protocol from the host ex-
ceeds the RX-BUF size the Reader responds with 0x81 PROTOCOL LENGTH ERROR.
TX-BUF:
TX-BUF is the maximum transmit buffer size of the Reader. The host has to take in to ac-
count that a response protocol of the Reader can have this length.
DEV_ID:
Individual device identifier of the Reader.
CUSTOM_L
Indicates which customer firmware is licensed on the Reader.
FW_L:
Indicates which Firmware version is licensed on the Reader.
TR_DRV_L:
Indicates which Transponder drivers are licensed on the Reader.
FNC_L
Indicates which optional functions are licensed on the Reader.
