OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 66 of 131 H60301-3e-ID-B.doc
DB-SIZE:
Number of bytes of one data block. This value depends on the specification of the Trans-
ponder manufacturer, see chapter 9.1. Supported ISO15693 Host commands for ISO15693
Transponders. DB-SIZE must be 1 for the I-Code EPC/UID Transponder.
DB:
Data of the data block to be written to the Transponder. The required block size is defined by
DB-SIZE. The number of the expected bytes are DB-N * DB-SIZE.
ISO15693 ERROR:
ISO15693 ERROR code of Transponder response. This byte is only available if STATUS =
0x95.
DB-ADR-E:
Block number where the error occurred.
Notes:
• A write to 1 block uses a Write Single Block command to the Transponder. This will be man-
aged by the Reader internally.
• If a Transponder does not supports Write Multiple Blocks commands several Write Single
Block commands are used for this Transponder.
• A write command on I-Code 1 Transponders can only be performed in the addressed mode.
• USB-reader: If the reader is set to 8 timeslots (for I-Code 1) a maximum of 5 blocks can be
written on an I-Code 1 transponder with one write command.
• If an error occurred during a write command, the number of the block where the error oc-
curred will be send to host
• If the Reader uses the “original I-Code Memory Model” see:3.5. CFG4: Transponder Parame-
ters the original I-Code address in DB-ADR must be used.
• A write command on I-Code EPC Transponders can only be performed in the non-addressed
mode whereas the block-size (DB-SIZE) must be 1 Byte.
• If an I-Code EPC Transponder is already locked, the reader answers with status = [0x03].
