Festo CMMS-AS-C4-3A-G2 Description

6 Positioning mode
Festo – GDCP-CMMS/D-FW-EN – 1404NH – Engli sh 125
Parameters: Positioning record number and profile
The diagra m shows the relationship between record selection/positioning record number/profile. A
positioning profile can be assigned to each positioning record via the “Profile” parameter.
Profile 31
2
Positioning record number
Record selection 1…63
Digital inputs/fieldbus
…
63
1 Positioning record list
2 Positioning record profiles
3 Positioning record profile number (0...7)
Parameter
Description
Position List Numbe r Selection of the positioning record.
– The positioning record in the individual record is selected via the
record selection of the control interface.
Profile Selection of a positioning record profile “0...7” (table “Positioning
record profiles”).
Tab. 6.5 Parameters: Positioning record number and profile
