Festo CPX-CMAX-C1-1 User Manual

4. Faults and diagnostics
4−26
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Fault group 6  error in valve
CPX error group 106 (CPX−MMI: [Error in valve])
No. Message Cause/description Error handling Type
1)
60 Faulty communication
with the valve or no
valve present
When switching on, only
the position measuring
system/sensor interface
was found. The valve
was not detected.
· Check cables to the
valve.
· Replace the valve.
Level: F2
Reset: N
Info: x
Communication between
CMAX and valve was in
terrupted
· Check the cables of
the axis string, the
valve and the sensor
step by step and ex
change, if necessary.
61 Valve hardware faulty
The valve reports a
hardware error.
· Replace the valve.
Level: F2
Reset: N
Info x
Fault in initialization of
the valve.
· Exchange valve, check
firmware update of
the CMAX.
Info: x
62 Valve over−temperature The valve reports over−
temperature. (Ambient
temperature too high).
· Provide sufficient
cooling.
Level: F2
Reset: F
Info: x
63 Valve is jammed The valve piston does
not move as expected.
· Replace the valve.
· Also check the air
quality (5−filter and
dry air).
Level: F2
Reset: F
Info: x
64 Load voltage of the valve
outside of the tolerance
range (undervoltage)
The valve reports in
sufficient load voltage.
Either the cable be
tween the CMAX and the
valve is faulty or the
valve.
· Check the cables at
the axis string.
· Check the valve, ex
change if necessary.
Level: F2
Reset: F
Info: x
1)
Level: fault level, see section 4.2.3; (can alternatively be parametrised as a warning or error)
Reset: behaviour upon reset, see section 4.2.4
Info:  = no info; x = additional info, see FCT or section 4.3.3
