5. Parameter
5−52
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
5.4.6 Project data
General description of the dimensional reference system, see
section B.2.
Project zero point
PNU PNU: 500 Index: 1 Max index: 1 Class: Var Data type: int32
Values Unit: Position (index = 1)
Linear drive Semi−rotary drive
Dimension Default Minimum Maximum Dimension Default Minimum Maximum
SI 0.01 mm 0 −1.000.000 1.000.000 0,1 ° 0 −100.000 100.000
Imperial 0.001 in 0 −393.701 393.701 0,1 ° 0 −100.000 100.000
Reference point for position values in the application. See section B.2.
o The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
ý After writing, controller recalculation is carried out.
