5. Parameter
5−93
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
5.4.16 System data
Actual hardware configuration
PNU PNU: 1190 Index: 1 Max index: 33 Class: Struct Data type: int32
Values see description of the respective index.
Default: 0 Minimum: − Maximum: −
Hardware configuration found after switching on (actual configuration).
Value 0 means that the parameter could not be recognized automatically.
The actual configuration contains the same parameters as the setpoint configuration (PNU 1100 to
1129). Units and values are identical. For comparison, the PNUs are listed here as well.
Index Value Value of setpoint
configuration Unit
1 Cylinder type PNU 1100
2 Cylinder effective length PNU 1101 Length (index 2)
3 Cylinder diameter PNU 1102 Diameter (index 11)
4 Piston rod diameter PNU 1103 Diameter (index 11)
5 Cylinder nominal length PNU 1101 Length (index 2)
10 Sensor type PNU 1110
11 Sensor length PNU 1111 Length (index 2)
12 Sensor serial number PNU 1112
13 Sensor resolution 1 m
14 Sampling time 1 sec
15 Sensor additional information
16 Firmware version
20 Valve 1 type PNU 1120
21 Valve 1 serial number PNU 1121
22 Valve 1 firmware version
23 Valve 1 hardware version
30 Valve 2 type PNU 1125
31 Valve 2 serial number PNU 1126
32 Valve 2 firmware version
33 Valve 2 hardware version
ý The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
o After writing, controller recalculation is carried out.
