Festo CPX-CMAX-C1-1 User Manual

4. Faults and diagnostics
4−44
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
4.4 Configuration of diagnostic messages and faults
PNU 228 permits the configuration of diagnostic events.
PNU 228: Configuration of diagnostic events
Index Description Default
1 Diagnostic events filter 0x0000000F
2 Fault messages filter 0x0000007F
3 Configuration of fault messages 0x000000C0
Tab.4/14: Configuration of the diagnostic messages
Diagnostic events filter
These settings allow you to determine which diagnostic ev
ents should be recorded. PNU 228:01 allows you to exclude
specific less important events from the diagnostic memory
records.
PNU 228:01: Diagnostic events filter
Which events other than faults do you want recording?
Bit Description Specifi
cation
0 Record warnings 1
1 Record configuration events (data reset, identification etc.) 1
2 Record reset commands 1
3 Record switch−on processes 1
4 ... 31 reserved (=: 0 !) 0
Tab.4/15: Configuration of the diagnostic messages  diagnostic events filter
