Festo CPX-CMAX-C1-1 User Manual

3. Drive functions
3−32
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
3.2 Commissioning operations
3.2.1 Movement test
The movement test is for detecting defects in the tubing con
nection.
Note
If the tubing connections of the VPWP get mixed up, the
control direction is reversed. When activating the con
troller, the drive would move at maximum speed into the
end position.
Carry out the movement test in the following cases:
· During commissioning after parametrisation. The CMAX
expects the movement test to be carried out after
parametrisation and indicates this by showing C03 on
the display.
· When components are exchanged or the tubing connec
tion has been disconnected and reconnected.
Special cases:
If the movement test is to be skipped (not recommended),
the status of the movement test must be set accordingly.
 The movement test status is automatically reset by the
CMAX in the event of faults E01 and E08.
If a movement test is to be carried out at a later time
(e.g. after exchanging hardware), the status of the move
ment test might have to be reset manually.
