1. CPX terminal configuration and FHPP overview
1−5
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
1.2 Data format
Multi−byte values are usually interpreted by CMAX in the byte
sequence INTEL (LSB−MSB)".
INTEL (LSB−MSB) − little endian
Example 21.268.514
d
= 01448822
h
Byte address 0 1 2 3
Bit no. 76543210 76543210 76543210 76543210
Bin 00100010 01000100 01000100 00000001
Hex 22h 88h 44h 01h
If your control system uses another byte sequence, you must
take this into consideration accordingly, e.g. in your applica 
tion programs.
CPX parameter Analogue process value representation"
A few CPX nodes (e.g. CPX−F B13, FB33, FB34 and FB35) sup
port the global system parameter Analogue process value
representation" (system table function number 4402, bit 7):
 Value 0": INTEL (LSB−MSB)  default
 Value 1": MOTOROLA (MSB−LSB)
MOTOROLA (MSB−LSB) − big endian
Example 21.268.514
d
= 01448822
h
Byte address 0 1 2 3
Bit no. 76543210 76543210 76543210 76543210
Bin 00000001 01000100 01000100 00100010
Hex 01h 44h 88h 22h
