B.3 Drives and measuring systems
The CMAX supports the following combinations of drive and
measuring system types.
Selecting a different combination is not possible in the FCT
and will lead to an error in the CMAX.
DGCI linear drive
Parameter Value
Measuring system type Prescribed: = Digital position measuring system
Cylinder length Nominal length/effective length
Measuring system length Prescribed = cylinder length
Offset axis zero point Prescribed = 0
Cylinder diameter Selection: 18, 25, 32, 40, 50, 63, 80, 100, 125
1)
Piston rod diameter 0
1)
In the CMAX drives with smaller or larger diameters will lead to errors here. A DGCI with a diameter
of e.g. 57 mm would be permissible, however.
Standard cylinders DNCI
Parameter Value
Measuring system type Prescribed: = encoder
Cylinder length 50 mm ... 10,000 N
Measuring system length Prescribed: = cylinder length
Offset axis zero point Selectable within the cylinder length
Cylinder diameter Selection: 32, 40, 50, 63, 80, 100, 125
1)
Piston rod diameter Smaller than cylinder diameter
1)
In the CMAX cylinders with smaller or larger diameters will lead to errors here. A DNCI with a
diameter of e.g. 57 mm would be permissible, however.
