C. Configuration with CPX node
C−3
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
C.1 CPX−FB13
General information on the CPX−FB13 are found in the de
scription on the P.BE−CPX−FB13−...
C.1.1 General configuration information
Identifier
Module (order code) Module
identifiers
Occupied bytes Identifier
Siemens / EN 50170
CPX−CMAX−C1−1 (T21) CMAX 8 bytes I, 8 bytes O 192 / C0
h
, 87
h
, 87
h
Device master file (GSD file) and icon files
Sources of supply Current GSD files and icon files can be found on the Festo
Internet pages at:
è www.festo.com è Downloads è Download Area: Soft
ware, drivers and firmware è Enter string: CMAX or GSD
GSD file You will require one of the following GSD files for the CPX
terminal with the CMAX:
 Cpx_059e.gsd (German
version)
 Cpx_059e.gse (English version)
Depending on the configuration program used, install the
GSD file and the icon files with the aid of the appropriate
menu command or copy the files manually into a particular
directory of your peripheral/PC.
