Festo CPX-CMAX-C1-1 User Manual

5. Parameter
5−67
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
5.4.10 Parameters of the default values
Default value speed position mode
PNU PNU: 600 Index: 1 Max index: 1 Class: Var Data type: int32
Values Unit: Speed (index = 6)
Linear drive Semi−rotary drive
Dimension Default Minimum Maximum Dimension Default Minimum Maximum
SI 0,001 m/s 2.000 10 10.000 1 °/s 1.000 10 10.000
Imperial 0.01 ft/s 650 3 3.281 1 °/s 1.000 10 10.000
This value contains the speed preset by the user. It is used in all records with position control where
no individual speeds are specified.
RPC−Bit = Bit 0 (= 00000001h)
o The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
o After writing, controller recalculation is carried out.
Default value speed force mode
PNU PNU: 601 Index: 1 Max index: 1 Class: Var Data type: int32
Values Unit: Speed (index = 6)
Linear drive Semi−rotary drive
Dimension Default Minimum Maximum
Force control is not permissible with semi−
d
SI 0,001 m/s 50 0 500
p
rotary drives.
Imperial 0.01 ft/s 15 0 164
This value contains the speed preset by the user. It is used in all records with force control where no
individual speeds are specified.
RPC−Bit = Bit 1 (= 0000.0002h)
o The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
o After writing, controller recalculation is carried out.
