Festo CPX-CMAX-C1-1 User Manual

6. Parametrisation
6−13
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
6.3 CPX module parameter and acyclic parametrising
6.3.1 CPX function numbers
Per module 64 byte module parameters (function no.
4828 + m*64 + 0...63) can be used in the system table.
CPX module parameter of the CMAX
Function no. Contents Description
4828 + m * 64 + 0 Module parameter 0
Standard module parameters, are not used by the
CMAX (reserved)
4828 + m * 64 + ... Module parameters ...
CMAX (reserved).
4828 + m * 64 + 5 Module parameter 5
4828 + m * 64 + 6 Module configuration 1 Special module settings of the CMAX (reserved).
4828 + m * 64 + 7 Module configuration 2
4828 + m * 64 + 8 Parameter control byte
Function head (request control)
4828 + m * 64 + 9 Parameter status byte
4828 + m * 64 + 10 Parameter function byte
4828 + m * 64 + 11 Parameter length byte
4828 + m * 64 + 12 Data byte 1
50 byte data.
The contents depend on the request
4828 + m * 64 + ... Data byte ...
The contents depend on the request.
4828 + m * 64 + 61 Data byte 50
4828 + m * 64 + 62 Byte 62
Not used (reserved).
4828 + m * 64 + 63 Byte 63
Tab.6/7: CPX module parameter of the CMAX
