1. CPX terminal configuration and FHPP overview
1−3
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
1.1 Planning aspects when parametrising the CMAX
1.1.1 Instructions on the available CPX nodes
Tab.1/1 shows an overview of the available CPX nodes
(CPX−FEC or CPX bus nodes) that are suitable for operation
with the CMAX (as of August 2009).
CPX node
Required version
1)
Use For a description see
CPX−CEC in preparation On request
CPX−FEC From Revision 18 (R18) On request Appendix C.3
CPX−FB6 (Interbus) From Revision 22 (R22) On request
CPX−FB11 (DeviceNet) From Revision 20 (R20) suitable Appendix C.2
CPX−FB13 (PROFIBUS−DP) From Revision 23 (R23) suitable Appendix C.1
CPX−FB14 (CANopen) From Revision 20 (R20) On request
CPX−FB23 (CC−Link) From Revision 19 (R19) On request
CPX−FB32 (Ethernet/IP) From Revision 11 (R11) On request
CPX−FB33 (PROFINET, M12) From Revision 7 (R7) On request
CPX−FB34 (PROFINET, RJ45) From Revision 7 (R7) On request
CPX−FB38 (EtherCAT) All On request
1)
Revisions version (Rev...), see name plate. Older revisions are not suitable for use with the CMAX
and can lead to unpredictable behaviour.
Tab.1/1: Instructions/special features/references for CPX nodes
General parametrisation instructions are provided in the
description for the used CPX node.
