4. Faults and diagnostics
4−42
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Diagnostic event 7: Switch on
The CMAX was switched on.
Diagnostic number
No. Description
1 Normal star t: Project data fully loaded.
2 Start in configuration mode C00: no project available.
3 Start in configuration mode C01: Project incomplete.
4 Start in configuration mode C02: Project incomplete.
5 Start in configuration mode C03: Movement test must be carried out.
Additional information
Info Description
Byte 1 Number of switch−on processes so far
Byte 2 reserved
Byte 3 + 4 Duty cycle in milliseconds
