Contents and general safety instructions
XVI
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Glossary
The following product−specific terms and abbreviations are
used in this manual:
Term / abbreviation
Meaning
0xA0 (A0
h
) Hexadecimal numbers are indicated by a prefixed 0x" or by a subscript h".
A Digital output.
From the point of view of the master controller, the CMAX control inputs are
module output data. See section 2.2.
AB Output by te.
Absolute position
measur in g system
A position measuri n g system with a fixed (absolute) assign ment of measured
value (position, angle, etc.) an d measured variable, for digital" or potentio
meter" CMAX.
Adaptati on CMAX function for au tom ati cal ly improving non−optimal control behaviour
during operation .
Axis string Totality of all modules and cables which are connected to the CMAX via the
axis interface.
Bus nodes Prov ide the connection to specific fieldbuses. Transmit control sign al s to the
con n e cted modules and monitor their functioni n g (as a CPX module: CPX bus
node).
CPX modules Collective term for the various modules which can be integrated in a CPX
termi nal .
CPX node Collective term for all CPX bus nodes or the CPX−FEC.
CPX terminal Complete system consisting of CPX modules with or without pneumatics.
Control interface Connection for all modules and cables in the axis string.
Drive In this description, the term drive" repres ents linear drives (DGCI, DGP),
standard cylinders or position in g drives (DNC, DNCI, DNCM) or swivel mod
ules (DSMI).
Festo Configuration Tool
(FCT)
Software with standardi sed project an d data management for supported
device types. The special requi remen ts of a device type are supported with
the necessary descriptions and dialog ues by means of plug−ins.
Festo Handling and
Positioning Profile (FHPP)
Fieldbus data profile for Festo position controllers.
