General procedure
The module parameters byte 8 ... 11 contain a function head
that controls the handshake between PLC and CMAX.
Design of the function head
Byte Name Description
PCB
Byte 8
(P8.0−P8.7)
Parameter
control byte
(PCB)
Request
0 =Do not execute request
1 = Request request for axis 1
PSB
Byte 9
(P9.0−P9.7)
Parameter
status byte
(PSB)
Result
0 = Request being processed
1 = Request processed successfully
General errors:
−1 = Request (PCB) faulty
−2 = Faulty function number (FFB)
−3 = system initialisation: Request cannot be executed
−4 =A request is already being processed
Error concerning function 1 (Festo Parameter Channel)
−10 = FPC: Number of parameters (byte 12) is wrong (permissible
1...7)
PFB
Byte 10
(P10.0−P10.7)
Parameter
function byte
(PFB)
Function number
0 =No function
1 = Festo Parameter Channel
PLB
Byte 11
(P11.0−P11.7)
Parameter
length byte
(PLB)
reserved for future extensions
must be set to 0
Tab.6/8: Function head
