Page #415 background imageLoading...
Page #415 background image
C. Configuration with CPX node
C−17
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Installing a modular EDS file
You will require the following files for the CPX terminal:
File type
File name Language Description
EDS cpx_chassis.eds English Base file for modular EDS.
EDS cpx_fb11...eds English Provides the communication adapter in the con
figuration program.
EDS cpx_...eds English There is an EDS file for every module type. It
contains the information needed for configur
ation and parametrisation.
ICO cpx_...ico Icon file for representing the CPX terminal or
mode in the configuration program.
Tab.C/4: Configuration files (modular EDS) for the CPX terminal for DeviceNet
Installing modular EDS
files
· Install the files with your configuration program.
You must install at least the Chassis EDS and the EDS files of
the required modules.
Recommendation: Install all EDS files.
Icon files Depending on the configuration program used, you can as
sign icon files (.ico format) to the CPX terminal or the CPX
modules. The CPX terminal
or the modules will then be repre
sented accordingly in the configuration program.
Notes on installing the EDS files and the icon files can be
found in the documentation for your configuration program.
