Festo CPX-CMAX-C1-1 User Manual

2. I/O data and sequence control
2−28
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Assignment of the status bytes (parametrisation)
SCON
Byte 1
B7
OPM2
B6
OPM1
B5
FCT_MMI
B4
24VL
B3
FAULT
B2
WARN
B1
OPEN
B0
ENABLED
y
Operati n g mode
ackn owled gemen t
Software
device
con tr ol
Load
voltage
applied
Fault Warning Operati on
enabl ed
Drive
enabl ed
Subindex
Byte 2
Subi n dex of the transferred parameter
Param.
identifier
Bytes 3+4
Reply identifier and parameter number:
Bit Conten t Description
0...11 PNU Param eter number of the parameter to be transferred
12 to 15 ResID Reply iden tifi er, see section 6.1.1
Param.
value
Bytes
5 to 8
Value of the parameter to be tran sferred
(32−bi t number)
