Flexim FLUXUS F60 Series User Manual

7 Connection
FLUXUS F60* 7.1 FLUXUS *601
53
UMFLUXUS_F60xV5-0EN, 2017-10-16
Connection of an output adapter
The number of outputs can be increased to max. 8 by connecting an output adapter (op-
tional), see Fig. 7.4 and Fig. 7.5.
passive
current
output
U
ext
= 4…26 V
U
ext
> 0.021 A · R
ext
[Ω] + 4 V
example:
U
ext
= 12 V
R
ext
≤ 500 Ω
frequency
output
U
ext
= 5…24 V
R
c
[kΩ] = U
ext
/I
c
[mA]
I
c
= 1…4 mA
binary
output
(optorelay)
U
ext
≤ 26 V
I
c
≤ 100 mA
process
interface
120 Ω
termination resistor
Fig. 7.5: Output adapter
Tab. 7.1: Circuit of the outputs
output transmitter external circuit remark
internal
circuit
connection
The number, type and the connections of the outputs depend on the order.
R
ext
is the sum of all ohmic resistances in the circuit (e.g., resistance of the conductors, resistance of
the amperemeter/voltmeter).
+
-
Px+
Px-
mA
U
ext
-
+
Px+
Px-
R
c
V
U
ext
+
-
Px+
Px-
R
c
V
U
ext
+
-
+
-
P5+
P5-
Output
-
+
P4P3 P5 P6 P7 P8
