7.2.5 Serial interface
• Connect the RS232 cable to the transmitter and the serial interface of the PC.
• Use the RS232 adapter for the connection of the RS232 cable to the transmitter. If the
RS232 cable cannot be connected to the PC, use the RS232/USB adapter.
The RS232 adapter, the RS232 cable and the RS232/USB adapter are part of the serial
data kit (optional).
Notice!
If a problem occurs when using the RS232/USB adapter for connection, contact
your system administrator.
Fig. 7.28: Connection of the serial interface to the transmitter FLUXUS *608**-A2
1 – serial interface
Fig. 7.29: Connection of the serial interface to the transmitter FLUXUS *608**-F2
1 – serial interface
CH A
COMM
Input Output
CH B
DC-IN
1
CH A
COMM
CH B
DC-IN
1
