5322A
Operators Manual
136
[SOUR]:SAF:LOOP:CORR(?) <CPD> { OFF | MAN | SCAN | COMP }
Description: This command sets the mode of residual impedance correction.
This command switches the Product into the Loop Impedance
function mode.
Parameters: <CPD> Parameter represents type of residual
impedance correction.
 OFF no correction
 MAN manual residual impedance
correction
 SCAN scanned residual impedance
correction
 COMP compensated residual
impedance correction
Example: SAF:LOOP:CORR MAN Manual correction of residual
impedance.
Query: SAF:LOOP:CORR MAN? Returns the type of residual
impedance correction.
[SOUR]:SAF:LOOP:POL?
Description: Returns the type of test signal generated by DUT { POS | NEG |
SYM | NO }. This command switches the Product into the Loop
Impedance function mode.
Query: SAF:LOOP:POL? Returns type of test signal generated by
DUT {POS | NEG | SYM | DCP | DCN | NO}
Types are:
 Test current is pulse (dc) with positive polarity (POS)
 Test current is pulse (dc) with negative polarity (NEG)
 Test current is symmetrical (ac) with positive phase (SYM)
Answer NO is sent in case an invalid test signal is generated.
[SOUR]:SAF:LOOP:CURR?
Description: This command returns the measured maximum (peak) value of
current flowing through the selected resistance. Maximum value
can be cleared using command SAF:LOOP:CLEar. Product returns
the current value using exponential format. Example: 215 mA is
returned as 215.0e-03. This command switches the Product into
the Loop Impedance function mode.
Query: SAF:LOOP:CURR?
[SOUR]:SAF:LOOP:CLE
Description: Clears the maximum (peak) value of current flowing through the
selected resistance. This command switches the Product into the
Loop Impedance function mode.
Example: SAF:LINE:CLE
