Configuring Channels 3-23.
These procedures provide instructions for configuring an instrument’s analog
channels and computed channels. These instructions include selecting the
measurement function, enabling Mx+B scaling, configuring alarms, and entering
channel labels.
The Channels Configuration Dialog Box 3-24.
All channels configuration procedures start with the Channels Configuration
dialog box shown in Figure 3-4.
To open the Channels Configuration dialog box, click
Instrument Configuration | Channels or double-click anywhere in the Channels
Configuration area of the Main Window (the lower portion).
Figure 3-4. Channels Configuration Dialog Box
