Preparing for Operation
Host Computer and Network Preparation
2
2-47
RJ-45 10BaseT
Outlets (Typical)
RJ-45
Interface
(Typical)
Patch Cord
Host
Computer 1
10Base2 Direct Connection
Unshielded Twisted-Pair Cable
WITH RX AND TX LINES REVERSED
Instrument
BNC “Y”
50-Ohm Terminator
with Ground Wire
BNC “T”
50-Ohm Terminator
Host
Computer 1
10BaseT Direct Connection
Instrument
10BaseT RJ-45 Ethernet Ports
10Base2 Coaxial Ethernet Ports
Ethernet
Coaxial Cable
(50-Ohm)
Ground Wire
(Instrument Only)
Ground
Wire
Terminal
Figure 2-32. Host Computer/Instrument Direct Connection
