Fluke NetDAQ 2640A User Manual

2640A/2645A NetDAQ
Users Manual
2-46
Instrument 1
Host
Computer 2
Host
Computer 1
Instrument 2
Instrument 3
Instrument 4
A typical isolated network configuration uses 10Base2 Coax for interconnection (shown).
BNC “T” or “Y”
(Typical)
10Base2 Coaxial
Cable (50-Ohm)
50-Ohm
Terminator
Connect to 10Base2
Coax Port
NetDAQ
NETWORKED DATA ACQUISITION UNIT
COMM DIO MON
ENTER
NetDAQ
NETWORKED DATA ACQUISITION UNIT
COMM DIO MON
ENTER
NetDAQ
NETWORKED DATA ACQUISITION UNIT
COMM DIO
MON
ENTER
Terminator
Ground Wire
COMM DIO MON
ENTER
NetDAQ
NETWORKED DATA ACQUISITION UNIT
Figure 2-31. Interconnection Using 10Base2 (Coaxial) Wiring
