Operating NetDAQ Logger for Windows
Introduction
4
4-3
Introduction 4-1.
This chapter provides instructions for operating your system using NetDAQ
Logger after you have set up communications and configured the instruments.
This includes starting and stopping logging, viewing and storing your data, and
optimizing system performance.
Starting and Stopping Logging 4-2.
You can start or stop logging for an individual instrument, a group instrument (by
starting or stopping the Master), or all instruments.
To start logging for an individual instrument, complete the following procedure:
1. Select the instrument’s icon. If the icon indicates “LOG” or “SIM,” the
instrument is already logging.
2. Select the Logging | Start Instrument or click the Start Instrument button on
the toolbar. If the menu command and button are dimmed, the instrument is
already logging, or it is a Slave instrument and you must start the Master.
