2640A/2645A NetDAQ
Users Manual
4-8
Instrument listed by BCN
Number of scans in the instrument scan queue
Number of scans retrieved and recorded.
Listing of channels where alarms have
occurred since the last status update.
AlarmBell is displayed
when at least one
channel is in alarm.
ds073c.eps
The Readings Table Window 4-10.
The Readings Table provides a numerical display of the most recent data
collected from the currently selected instrument. Complete the following
procedure to use the Readings Table window:
1. Select Options | Show Current Readings to display the Readings Table
window.
