sensALIGN 5 EX sensor
Type 5-axis sensor: 2 planes (4 displacement axes and angle)
LED indicators 2 LEDs for laser adjustment
Environmental pro-
tection
IP65 (dustproof and water jets resistant), shockproof
Relative humidity: 10% to 90%
Ambient light pro-
tection
Yes
Temperature
range
Operation: -10°C to 50°C (14°F to 122°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Dimensions Approx. 105 x 74 x 53 mm (4 9/64" x 2 29/32" x 2 3/32")
Weight Approx. 220 g (7.7 oz)
Measurement
range
Unlimited, dynamically extendible (US. Patent 6,040,903)
Measurement res-
olution
1 μm (0.04 mil) and angular 10 μRad
Measurement rate Approx. 20 Hz
Measurement
accuracy (avg)
> 98 %
CEconformity Refer to the CE compliance certificate in www.pruftechnik.com
Intrinsic safety II 2G Ex ib IIC T4 Gb, Zone 1
Certificate numbers: EPS 15 ATEX 1074X; IECExEPS 15.0067X
Electrical data
Only for connection with certified equipment for power supply
and data acquisition. The following intrinsic safe values (float-
ing ground) shall never be exceeded:
Supply circuit Uo,v = 6 V
Data circuit Uo,d = +6 V
Output current for both circuits in summary Io,v + Io,d = 215 mA
Output power for both circuits in summary Po,v + Po,d = 1.25 W
Supply characteristic rectangular
Maximum permissible external capacitance for Lo < 2 μH Co = 30µF
