Internal capacitance of sensALIGN 5 EX sensor Ci = 25.2 µF
Internal inductance of sensALIGN 5 EX sensor Li = 0 µH
The supply circuit and the data circuits must be considered to be internally connected. lt must
be ensured that safety-relevant circuit parts are never damaged by feeding back power to the
connected devices.
For connection with equipment for power sup-
ply and data acquisition, e.g. the following
devices provided by PRÜFTECHNIK:
RF module EX, type ALI 4.621 EX
162 Version:2.3
