5-2-2. Front Panel Stored Salvos
This type of salvo allows to you assign crosspoints to be simultaneously switched to a front
panel button.
Storing Front Panel Salvo Data
Front panel salvo data can be stored using the Web-based Control.
► See [Web-based Control: Salvo page]
Executing Salvos
Use a SALVO (SALVO RECALL(FP)) button on the front panel as shown in the procedure
below.
(1) Assign a SALVO button on the front panel. Set the salvo for FP RECALL, and select a
Salvo number.
► See Sec. 4-4-4. "Button Assign Menu."
(2) Pressing the SALVO button to executes the salvo. The crosspoints stored to the salvo
number are simultaneously set.
5-2-3. Simultaneous Switching Using Take Function
The TAKE button on the front panel allows you to simultaneously switch preset crosspoints.
Executing a TAKE
See the Ex. 1) and Ex. 2) in section 5-1-4. “Crosspoint Switching Using TAKE Function” for
the procedure.
5-2-4. Simultaneous Switching by Link Function
The LINK button on the front panel allows you to simultaneously switch crosspoints
associated with a specific crosspoint.
Pressing the front panel LINK button enables or disables the Link function. The LINK button
is highlighted with a bright background when the function is enabled.
If the Link function is turned on, selecting a trigger crosspoint switches the slave crosspoints
with it. The trigger and slave crosspoints can be assigned using Web-based Control.
► See [Web-based Control: Link Settings page] for more details.
