FOR-A MFR-3000 User Manual

87
MON-OUT
NO.
Number of monitor output
MFR-5000/8
000 only
O-PREV
DESTINATION
Destination channel
SALVO
TYPE
MU: Execution of an MU salvo.
RU: Execution of an RU button salvo
STORE: Registration of an MU salvo
NO.
Salvo number
When TYPE
is set to MU
or RU:
5-4-4-5. INHIBIT
The following submenus are available in INHIBIT Setting mode.
Submenu
Description
DEST
Allows you to set INHIBIT to enabled / disabled for a destination
channel. Symbol "X" appears on channels when INHIBIT is enabled.
SRC
Allows you to set INHIBIT to enabled / disabled for a source channel.
Symbol "X" appears on channels when INHIBIT is enabled.
INHIBIT > DEST
Displays the destination channel list. Press a channel to enable/disable the INHIBIT
function.
INHIBIT > SRC
Displays the source channel list. Press a channel to enable/disable the INHIBIT function.
5-4-4-6. NAME TYPE
Menu List
Menu Item
Description
Set by
DEST
Allows you to select the display format for a
destination button.
Pressing a button
SRC
Allows you to select a display format for a source
button.
Pressing a button
LEVEL
Allows you to select the display format for a level
button.
Pressing a button
Available formats are as shown in the table below.
Display
format
Description
Display example
DST
SRC
LEVEL
PHY NUM
Physical number display
ASCII
Ascii character display
(Alphanumeric characters and
symbols)
KANJI
2-byte character code including
1-byte character code
(Not selectable for LEVEL)
* When using 2-byte characters:
Up to 8 characters (including one-byte characters) on MFR-39RUA/18RUA/16RUTA
units
Up to 4 characters (including one-byte characters) on MFR-39RU/18RU units
* Up 14 characters when using only one-byte characters
