FOR-A MFR-3000 - Video Format Commands (12)

89
8-3-8. Video Format Commands (12)
Video Format Commands allow you to change router video format. The router restarts
automatically when commands are sent out. The commands can also change reference and
switching point settings.
 Command Format
Command description
Commands
Command response
(1)
Sets video format,
reference and/or switching
point beforehand.
@[sp]UF:<YY>/<R#>,<S$>
*1
UF!<YY>/<R#>,<S$>
(2)
Performs the set changes.
@[sp]UE:A
UR!W
*2
UR!<YY>/<R#>,<S$>
UR!E
(error response)
(3)
Cancels the set changes.
@[sp]UE:C
UR!C
*1
Reference and Switching points are non-compulsory. When they are not input, present
settings are output for command response.
*2
“UR!W” is output at 5-seconds intervals after receiving “@[sp]UE:A.” When execution
environment is ready, “UR!<YY>/<R#>,<S$>” is output.
Commands
BYTE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
(1)
@
[sp]
U
F
:
<YY>
/
<R#>
,
<S$>
CR
(2)
@
[sp]
U
E
:
A
CR
(3)
@
[sp]
U
E
:
C
CR
Parameters
<YY>
Video format
00: 1080/59.94i
01: 1080/59.94p
02: 1080/60i
03: 1080/60p
04: 1080/50i
05: 1080/50p
06:720/60p
07: 720/59.94p
08: 720/50p
09: 1080/30p
0A: 1080/29.97p
0B: 1080/25p
0C: 1080/24p
0D: 1080/23.98p
0E: 1080/30psF
0F: 1080/29.97psF
10: 1080/25psF
11: 1080/24psF
12: 1080/23.98psF
13: NTSC
14: PAL
<R#>
Reference
RA: Auto
RB: B.B
RT: Tri-Sync
<S$>
Switching point
SF: Field
SO: Odd
SE: Even
* Commands are not executed if no video format is set or the current video format is set.
 Command Example 1
Changes Video Format to 720/59.94p.
Command
Command response
@[sp]UF:07[CR]
[CR][LF]UF!07/RA,SF[CR]
@[sp]UE:A[CR]
[CR][LF]UR!W
[CR][LF]UR!07/RA,SF[CR]
(The router automatically restarts)
 Command Example 2
Changes Video Format to 1080/59.94p, Reference to Tri-level Sync and Switching Point to
Field.
Command
Command response
@[sp]UF:01/RT,SF[CR]
[CR][LF]UF!01/RT,SF[CR]
@[sp]UE:A[CR]
[CR][LF]UR!W
[CR][LF]UR!01/RT,SF[CR]
(The router automatically restarts)
