30
Channels 17 to 24
Channels 25 to 32
2-4-3. MFR-16ADI (AES Input with SRC)
MFR-16ADI is an AES/EBU audio input card with SRC.
Up to 4 cards can be installed into Slot No. 05 to 08.
► See section 2-1-1. "Matrix Size Chart."
BNC x 16 inputs (16 stereo pairs, 32 channels), unbalanced, 75 Ohm
When using an MFR-16ADI, a Black Burst signal should be input to REF IN2.
To output the MFR-16ADI digital audio input, use MFR-16ADAO. The
MFR-16AESO/16AAOEX cannot output MFR-16ADI audio channels.
SRC (Sample Rate Converter)
A Sample Rate Converter is implemented in MFR-16ADI cards.
It allows you to accept audio signals of the following frequencies:
32 kHz, 44.1 kHz, 48 kHz and 96 kHz
19/20
21/22
29/30
27/28
25/26
23/24
17/18
15/16
13/14
11/12
9/10
7/8
5/6
3/4
31/32
1/2
ADI
(No.)
