67
5-2. Basic Operation on Control Panels
This section describes basic operation of the remote control panel and how to set and execute
various functions.
5-2-1. Buttons
1) Assign functions to buttons (change assignments)
To use buttons on the remote control panel, assign functions to the buttons in the Web-based
Control: Assign Function page]. Any function can be assigned to any button except the
CANCEL, PAGE A, PAGE B, UP, DOWN and ENTER buttons.
Button Assign Procedure
(1) In the Web-based Control, click to open the menu tree at the left side. Click to select
Assign Function to display the menu page.
(2) Set the page, button and function respectively to assign functions to buttons. Buttons can
be selected by specifying Button IDs or clicking on button icons.
(3) After selecting a function, set the function specific settings.
(4) After all settings are completed, click Send to apply the settings.
The MFR-39RU menu display can also assign functions.
► See section 5-4-3-12 “BTN ASSIGN”
The MFR-39RUA menu display can also assign functions.
► See section 5-4-4-4 “BUTTON ASSIGN”
Source and destination button/channel assignments can be performed using the control
knob on MFR-18RU/ 16RUTA/18RUA / 39RUA units.
► See section 5-2-3. “Control Knob”
MFR-16RUD can perform assignments using the display on the front panel.
► See section 5-5-2 “Changing Button Assignments” for details
2) Press buttons to execute functions
Press a button to execute the assigned function. The button LED indication, NAME
DISPLAY, and MENU display change according to the assigned function.
