65
4-5. SETTINGS
1. MFR-LAN
[ IP ADDRESS ]
Step
Display
Description
1
Allows you to set the IP address.
(For MFR-LAN/LAN (TO RU) connection)
[ NET MASK ]
Step
Display
Description
1
Allows you to set the subnet mask.
(255.0.0.0 to 255.255.255.254)
(For MFR-LAN/LAN (TO RU) connection)
2. MU SETTING
[ MENU BRIGHTNESS ]
Step
Display
Description
1
Allows you to set the menu display
brightness.
brightness: 1 (dark) to 15 (bright)
[ REFERENCE ]
Step
Display
Description
1
Allows you to select how to select a
reference signal format.
AUTO: Automatic detection
MANUAL: Manual selection
If set to MANUAL, select a signal below.
2
Allows you to select a reference signal
from BB or TRI-SYNC.
[ FORMAT ]
Step
Display
Description
1
Allows you to select a video format
[ PS2 INSTALL ]
Step
Display
Description
1
Displays whether the redundant power
supply unit is present.
[ SHUT DOWN ]
Step
Display
Description
1
Allows you to select a slot to shut down.
2
Select OFF to shut down.
Select ON to supply power.
* When selecting the following functions, the confirmation display appears. (Select OK to
execute the function.)
â– CPU REDUNDANT: Manually switches CPU cards 1 and 2.
Requires time for sharing files between CPUs after startup or
CPU changeover, during which crosspoint switchings cannot
be performed.
â– PC-LAN(IP ADDRESS INFO / NET MASK INFO / GATEWAY INFO):
Displays the PC-LAN port settings.
â– PC-LAN REBOOT: Restarts the PC-LAN port.
