4. Front Panel (MFR-30FP) Operation
4-1. Functions and Operations
The below table shows the functions that can be controlled using the front panel and/or
Web-based Control (GUI).
* For details on Web-based Control operation, see the separate MFR SERIES Web-based
Control Operation Manual.
Description on Control
○: Changing settings and execution are both supported
●: Execution is supported
▲: Changing settings is supported
Controller
Function
Front Control
Panel
Web-based
Control
Ref.
Crosspoint
change
(1 channel)
By changing source and/or destination
○
○
5-1-1
Using bus buttons
○
---
5-1-2
Using the menu
○
---
4-4-3
CHOP function
●
---
5-1-3
TAKE function
●
○
5-1-4
Crosspoint
change
(Simultaneous)
Main unit stored SALVO
●
▲
5-2-1
Front panel button assigned SALVO
●
▲
5-2-2
TAKE function
●
○
5-2-3
LINK function
●
▲
5-2-4
Erroneous
operation
protection
LOCK LOCAL
○
---
5-3-1
LOCK OTHER/ALL
○
○
5-3-2
Crosspoint inhibit
---
○
Web
Operation Preview function
●
---
5-4
Main unit and
system setting
change
Source/destination name settings
---
○
Web
System tally settings
---
○
Web
MFR-LAN settings
▲
▲
4-4-6-2
PC-LAN rebooting
▲
▲
4-4-6-3
Front panel
setting change
Button assignment
○
○
4-4-4
PAGE function
○
▲
Web
Group setting
○
○
4-4-5
Menu screen and button brightness
adjustment
▲
▲
4-4-6-1
Status display
●
●
4-4-6-4
Alarm indication
●
●
4-4-6-4
