10. Specifications and Dimensions
10-1. Unit Specifications
10-1-1. MFR-3000
Video Formats
12G-SDI
2160/59.94p, 2160/50p
3G-SDI
1080/60p, 1080/59.94p, 1080/50p
HD-SDI
1080/60i, 1080/59.94i, 1080/50i,
1080/30p, 1080/30PsF, 1080/29.97p, 1080/29.97PsF, 1080/23.98p,
1080/23.98PsF, 1080/25p, 1080/25PsF, 1080/24PsF, 1080/24p,
720/60p, 720/59.94p, 720/50p
SD-SDI
525/60, 625/50
Matrix Size
Min. 8 x 8 to Max. 64 x 64
Number of input slots: 8
Number of output slots: 8
(Expandable on a 8-channel basis)
Video Input
MFR-8SDI
SDI Input Card (Max. 8 cards)
- BNC x 8
Compliant with the following (75Ω BNC)
- SMPTE424M (3G-SDI)
- SMPTE292M (HD-SDI)
- SMPTE259M (SD-SDI)
- DVB-ASI
Cable Equalization
3G/HD-SDI: 100 m (5C-FB cable)
SD-SDI: 200 m (5C-2V cable)
MFR-8SDIGB
SDI Input Card (Max. 8 cards)
- BNC x 2 (12G-SDI or 3G-SDI)
- BNC x 6 (3G-SDI)
Compliant with the following standards (75Ω BNC)
- SMPTE ST 2082-10 (12G-SDI)
- SMPTE ST 425-5 (Quad Link 3G-SDI)
I/O delay selection
Delay (H) (0.3H-1H), 1 frame, 1 frame+ Delay (H)
Video Output
MFR-8SDO
SDI Output Card (Max. 8 cards)
- BNC x 8
Compliant with the following (75Ω BNC) (Auto reclocking)
- SMPTE 424M (2.97 Gbps, 2.97/1.001 Gbps)
- SMPTE292M (1.485 Gbps, 1.485/1.001 Gbps)
- SMPTE259M (270 Mbps)
- DVB-ASI
MFR-8SDOGB
SDI Output Card (Max. 8 cards)
- BNC x 2 (12G-SDI or 3G-SDI)
- BNC x 6 (3G-SDI)
Compliant with the following (75Ω BNC)
- SMPTE ST 2082-10 (12G-SDI)
- SMPTE ST 425-5 (Quad Link 3G-SDI)
I/O delay selection
Delay (H) (0.3H-1H), 1 frame, 1 frame+ Delay (H)
