92
Analog Audio Input Card with A/D converter (Max. 8 cards)
- 25-pin D-sub (female) x 2 (8 stereo pairs, 16 channels)
- Balanced or unbalanced, 600 ohm or high impedance
- Sampling frequency: 48kHz
AES/EBU Audio Input Card (Max. 8 cards)
- BNC x 8 (8 stereo pairs, 16 channels)
- 75 ohm, BNC
Analog Audio Output Card with D/A converter (Max. 8 cards)
- 25-pin D-sub (female) x 2 (8 stereo pairs. 16 channels),
- Balanced or unbalanced, less than 100Ω, 48 kHz
AES/EBU Audio Output Card (Max. 8 cards)
- BNC x 8 (8 stereo pairs. 16 channels)
- 75 ohm BNC
16 SDI output card with multiviewer function (Up to 4 cards)
- 2 slots required per card
- BNC x 16
- 75 ohm BNC
BB: 0.429 Vp-p (NTSC)/0.45 Vp-p (PAL) or Tri-level Sync: 0.6 Vp-p
75Ω BNC x 1, loop-through (Terminate with 75Ω terminator, it unused.)
10/100/1000 Base-T, RJ-45 x 2
(For connecting up to 128 RU/GPI units.)
(Second LAN port used in redundant CPU configuration)
10/100 Base-TX, RJ-45 x 1 (for PC operation)
RS-232C/RS-422 (Internal switch), 9-pin D-sub (male) x 1
9-pin D-sub (female) x 1
(Input: Reset, Output: Power alarm, fan alarm, crosspoint error, CPU
changeover and secondary CPU error)
30% to 85% (no condensation)
100 VAC to 240 VAC ±10%, 50/60Hz IN x 2
(MFR-30PS required for redundant power configuration)
When performing 64 x 64 SDI signal routing:
150 VA (145W) at 100 - 120 V AC,
198 VA (136W) at 220 - 240 V AC
* The power consumption may increase up to the following maximum
value if performing different signal routing such as video and audio
routing.
100 V AC to 120 V AC: 671 VA (661 W),
200 V AC to 240 V AC: 608 VA (510 W)
482 (W) x 177 (H) x 350 (D) mm EIA 4RU
18 kg (with full options)
Consumables
(24 hours in room
temperature)
Power supply unit: Replace every 5 years
FAN 1 & 2 (rear) : P-1529 Replace every 4 years
FAN 3 & 4 (front) : P-1567 Replace every 4 years
FAN 3 & 4 (front) :P-1528 Replace every 4 years (Firmware version less
than 1.81)
MFR-16MV button battery: CR2032. Replace every 5 years
