FOR-A MFR-3000 - 6 Multiview Output; Multiviewer Specifications

64
6. Multiview Output
The MFR-16MV card allows you to output multiview images using any two BNC connectors, in
which up to 16 video windows and two clocks can be displayed on a single or dual multiview
screen.
 Process Block Diagram
Any router sources can be used as multiview window sources. Assign multiview output to desired
destination channel(s). Other ports on the card can function as router destination channel outputs.
6-1. Multiviewer Specifications
Item
Specifications
Video format
3Gbps (Level-A)
1080/60p, 59.94p, 50p
1.5Gbps (HD)
1080/60i, 59.94i, 50i, 720/60p, 59.94p, 50p,
1080/30p, 29.97p, 25p, 24p, 23.98p,
1080/30psF, 29.97psF, 25psF, 24psF, 23.98psF
Video input
SDI 75Ω BNC 16 inputs (Including asynchronous inputs*)
Video output
SDI 75Ω BNC x 16
Audio output
(Except MV outputs)
Embedded (SDI)
- Group x 4, 8 stereo pairs
- Sampling frequency: 48 kHz
- Quantization bit: 24-bit
Input/output delay
1 frame (with synchronous inputs)
Number of windows
16 video windows and 2 clocks (selectable from 10 types)
Window size
16, 9 or 4
