QUANTUM™ LX EVAPORATOR CONTROL PANEL
OPERATION
090.610-O (MAR 2016)
Page 40
SYSTEM STATUS - Trending – Real Time Data Log
DESCRIPTION: This screen will display in a tabular format, the
numerical data values selected on the Real Time Trending Set-
up screen. Each trending channel will be listed at the bottom of
the screen in a specic color that matches all data associated
with that channel.
The following are the possible data channels that may be
shown here:
• ZONE #1-30 - Return Air Temperature
• ZONE #1-30 – Ammonia
• ZONE #1-30 – Humidity
Up to eight of these data selections may be activated at any
one time. If eight items are selected, and you wish to view
one more, you will rst need to de-activate one that is already
chosen rst.
