5.4 Details of Function Codes
5-123
Details of
Function Codes
F codes
E01 to E09
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U codes
y codes
Chapter 5 Function Code
Table 5.4-63
Data Control Method
Active
ON
Active
OFF
Defined Function
Signal
Name
V/f
PG
V/f
PG
less
PG
Torque
Control
Related
Function
Code
14 1014 Torque limit 2/Torque limit 1 TL2/TL1
{ { { { {
F40, F41
E16, E17
15 ― Switch to commercial power (50 Hz) SW50
{ {
XX X ―
16 ― Switch to commercial power (60 Hz) SW60
{ {
XX X ―
17 1017 UP command UP
{ { { {
X
18 1018 DOWN command DOWN
{ { { {
X
Frequency
setting:
F01, C30
PID
command:
J02
19 1019
Edit accept command (data change
possible)
WE-KP
{ { { { {
F00
20 1020 Cancel PID control Hz/PID
{ { { {
X
J01 to J19,
J56 to J62
21 1021 Switch normal/inverse operation IVS
{ { { {
X C53, J01
22 1022 Interlock IL
{ { { { {
F14
23 1023 Cancel torque control Hz/TRQ XXXX
{
H18
24 1024
Link operation select
(RS-485, BUS option)
LE
{ { { { {
H30, y98
25 1025 Universal DI U-DI
{ { { { {
―
26 1026 Select starting mode STM
{ { {
X
{
H09, d67
1030 30 Forcible stop STOP
{ { { { {
F07, H56
32 1032 Pre-excitation EXITE XX
{ {
X H84 and H85
33 1033
Reset PID integral and differential
components
PID-RST
{ { { {
X
34 1034 Hold PID integral component PID-HLD
{ { { {
X
J01 to J19,
J56 to J62
35 1035 Local (keypad) command select LOC
{ { { { {
(See Item
3.3.6.)
36 1036 Motor select 3 M3
{ { { { {
A42, b42
37 1037 Motor select 4 M4
{ { { { {
A42, r42
39 ― Dew condensation prevention DWP
{ { { { {
J21
40 ―
Commercial power switching integrated
sequence (50 Hz)
ISW50
{ {
XX X
41 ―
Commercial power switching integrated
sequence (60 Hz)
ISW60
{ {
XX X
J22
47 1047 Servo-lock command LOCK XXX
{
X J97 to J99
48 ―
Pulse train input (available only on
terminal [X7])
PIN
{ { { { {
49 1049
Pulse train sign (available on terminals
except [X7])
SIGN
{ { { { {
F01, C30
d62, d63
59 1059 Battery run effective command BATRY
{ { { { {
70 1070 Cancel constant peripheral speed control Hz/LSC
{ { { {
X
71 1071
Constant periphery speed control
frequency memory
LSC-HLD
{ { { {
X
d41
72 1072
Input during commercial driving
(Motor 1)
CRUN-M1
{ {
XX
{
73 1073
Input during commercial driving
(Motor 2)
CRUN-M2
{ {
XX
{
74 1074
Input during commercial driving
(Motor 3)
CRUN-M3
{ {
XX
{
75 1075
Input during commercial driving
(Motor 4)
CRUN-M4
{ {
XX
{
H44, H94
76 1076 Droop select DROOP
{ { { {
X H28
