5.4 Details of Function Codes
5-124
Data Control Method
Active
ON
Active
OFF
Defined Function
Signal
Name
V/f
PG
V/f
PG
less
PG
Torque
Control
Related
Function
Code
77 1077 Cancel PG alarm PG-CCL X
{
X
{ {
―
80 1080 Cancel customizable logic CLC
{ { { { {
81 1081
Clear
all customizable logic timers
CLTC
{ { { { {
E01 to E09,
U81 to U85
98 ―
Normal operation, Stop command
(Setting possible to terminals [FWD]
and [REV] only by E98 and E99)
FWD
{ { { { {
99 ―
Inverse operation, Stop command
(Setting possible to terminals [FWD]
and [REV] only by E98 and E99)
REV
{ { { { {
F02
100 ― No function NONE
{ { { { {
U81 to U85
110 1110 Select servo lock gain SLG2 XXX
{
X d27, d28
1111 111 Forcible stop (terminal block only) STOP-T
{ { { { {
Functions that has "-" in the data active OFF field, negative logic setting is not possible.
The external alarm and forcible stop have the fail-safe setting as default. For example, take note
that data = 9 is "Active OFF" (alarm is triggered when OFF), and data = 1009 is "Active ON"
(alarm is triggered when ON).
