5.4 Details of Function Codes
5-167
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C01 to C19
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U codes
y codes
Frequencies that can be selected by combinations of SS1, SS2, SS4 and SS8 are as follows.
Table 5.4-91
SS8
SS4 SS2 SS1 Selected frequency
OFF
OFF OFF OFF Other than multi-frequency
*
OFF
OFF OFF ON C05 (multi-frequency 1)
OFF
OFF ON OFF C06 (multi-frequency 2)
OFF
OFF ON ON C07 (multi-frequency 3)
OFF
ON OFF OFF C08 (multi-frequency 4)
OFF
ON OFF ON C09 (multi-frequency 5)
OFF
ON ON OFF C10 (multi-frequency 6)
OFF
ON ON ON C11 (multi-frequency 7)
ON
OFF OFF OFF C12 (multi-frequency 8)
ON
OFF OFF ON C13 (multi-frequency 9)
ON
OFF ON OFF C14 (multi-frequency 10)
ON
OFF ON ON C15 (multi-frequency 11)
ON
ON OFF OFF C16 (multi-frequency 12)
ON
ON OFF ON C17 (multi-frequency 13)
ON
ON ON OFF C18 (multi-frequency 14)
ON
ON ON ON C19 (multi-frequency 15)
* "Other than multi-frequency" includes frequency command 1 (F01), frequency command 2 (C30), and
other frequency setting input method excluding multi-frequency commands.
When enabling PID control (J01 = 1 to 3)
The PID control command can be set as the preset value (3-stage). In addition, multi-frequency (3-stages)
can be also used for the manual speed command and dancer control in the PID control cancel (Hz/PID =
ON).
- PID control command
Table 5.4-92
SS8 SS4 SS1, SS2 Selected command
OFF OFF - Command specified by J02
OFF ON - C08
ON OFF - C12
ON ON - C16
C08, C12, and C16 can be set in increments of 1 Hz. Convert the PID control command and the set data by
using the following conversion formula .
Setting data = PID control command (%) x Maximum output frequency (F03)/100
