5.4 Details of Function Codes
5-173
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C21 to C88
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U codes
y codes
C30
Frequency Command 2 (See F01)
For details of frequency command 2, see the description of the function code F01.
C31 to
C35
C36 to
C40
C41 to
C45
Analogue Input Adjustment (Terminal [12]) (Offset Gain Filter Gain Base Point and
Polarity Selection)
Analogue Input Adjustment (Terminal [C1]) (Offset Gain Filter Gain Base Point and
Range Selection)
Analogue Input Adjustment (Terminal [V2]) (Offset Gain Filter Gain Base Point
Polarity Selection)
For Frequency Setting, (See F01)
Setting the frequency using analog input
Gain, polarity selection, filter, and offset adjustment are possible to the analog input (voltage to be input to
terminal [12] and terminal [V2] and current to be input to terminal [C1]).
Adjustable items for analog inputs
Table 5.4-100
Gain
Input
terminal
Input range
Gain Base point
Polarity Selection
/Range Selection
Filter Offset
[12]
0 to +10 V, -10 to +10 V
C32 C34 C35 C33 C31
[C1]
4 to 20 mA, 0 to 20 mA
C37 C39 C40 C38 C36
[V2]
0 to +10 V, -10 to +10 V
C42 C44 C45 C43 C41
Offset (C31, C36, C41)
C31, C36 or C41 configures an offset for an analog input voltage/current. The offset of the signal from
external equipment can be also corrected.
- Data setting range: -5.0 to +5.0 (%)
Filter (C33, C38, C43)
C33, C38, or C43 sets the filter time constant for the analog input voltage/current. Choose appropriate
values for the time constants considering the response speed of the machinery system, as large time
constants slow down the response. If the input voltage fluctuates because of noise, set a large time constant.
- Data setting range: 0.00 to 5.00 (s)
Polarity selection (C35, C45)
C35 or C45 sets the input range for analog input voltage.
Table 5.4-101
Data for C35 and C45 Terminal input specifications
0
-10 to +10 V
1
0 to +10 V (negative voltage value is regarded as 0 V)
