5.4 Details of Function Codes
5-244
Torque Command/Torque Current Command
By the analog voltage input (terminal 12, V2), analog current input terminal (C1), or communication
(function code S02, S03), the torque command/torque current can be applied.
(When analog voltage input/analog current input is used, set the function code E61 (terminal 12),
E62 (terminal C1), and E63 (terminal V2) to 10 or 11 as shown in the following table.)
Table 5.4-167
Input Command Form
Function
Code
Definition of monitor amount 100%
(factory default)
Torque command E61 = 10
Motor rated torque ±100% / ±10 V
Terminal [12]
(-10 V to 10 V) Torque current
command
E61 = 11 Motor rated torque current ±100% / ±10V
Torque command E63 = 10
Motor rated torque ±100% / ±10 V
Terminal [V2]
(-10 V to 10 V) Torque current
command
E63 = 11 Motor rated torque current ±100% / ±10V
Torque command E62 = 10
Motor rated torque 100% / 20 mA
Terminal [C1]
(0, 4 to 20 mA) Torque current
command
E62 = 11 Motor rated torque current 100% / 20 mA
S02 (-327.68 to
327.67%)
Torque command - Motor rated torque / ±100.00%
S03
(-327.68 to 327.67%)
Torque current
command
- Motor rated torque current / ±100.00%
The function codes C31 to C45 (analog input adjustment) are applied to these analog inputs.
Speed control
The response of speed control can be adjusted by adjusting the following speed control P gain and
integral time.
Table 5.4-168
Function Code
Selected Motor
P Gain
Integral
Time
M1 d03 d04
M2 A45 A46
M3 b45 b46
M4 r45 r46
