5.4 Details of Function Codes
5-251
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U00 to U91
y codes
Data Selectable Signal
2008 (3008) Output of step 8 SO08
2009 (3009) Output of step 9 SO09
2010 (3010) Output of step 10 SO10
4001 (5001) X1 terminal input signal, X1
4002 (5002) X2 terminal input signal X2
4003 (5003) X3 terminal input signal X3
4004 (5004) X4 terminal input signal X4
4005 (5005) X5 terminal input signal X5
4006 (5006) X6 terminal input signal X6
4007 (5007) X7 terminal input signal X7
4008 (5008) X8 terminal input signal X8
4009 (5009) X9 terminal input signal X9
4010 (5010) FWD terminal input signal FWD
4011 (5011) REV terminal input signal REV
6000 (7000) Final run command RUN FL_RUN: ON when frequency command is not 0 and a run
command is given.
6001 (7001) Final run command FWD FL_FWD: ON when frequency command is not 0, and a run
forward command is given.
6002 (7002) Final run command REV FL_REV: ON when frequency command is not 0, and a run
reverse command is given.
6003 (7003) During acceleration DACC: ON during acceleration
6004 (7004) During deceleration DDEC: ON during deceleration
6005 (7005) Under anti-regenerative control REGA: ON under anti-regenerative control
6006 (7006) Within dancer basic position DR_REF: ON when the dancer roll position is within the
reference range
6007 (7007) Alarm factor presence ALM_ACT: ON when there is no alarm factor
Logic circuit (U03, etc.)
Any of the following functions is selectable as a logic circuit (with general-purpose timer).
Table 5.4-179
Data Function Description
0 No function assigned Output is always OFF.
1 Through output + General-purpose
timer
Only a general-purpose timer. No logic circuit exists.
2 ANDing + General-purpose timer AND circuit with 2 inputs and 1 output, plus general-purpose timer.
3 ORing + General-purpose timer OR circuit with 2 inputs and 1 output, plus general-purpose timer.
4 XORing + General-purpose timer XOR circuit with 2 inputs and 1 output, plus general-purpose timer.
5 Set priority flip-flop +
General-purpose timer
Set priority flip-flop with 2 inputs and 1 output, plus
general-purpose timer.
6 Reset priority flip-flop +
General-purpose timer
Reset priority flip-flop with 2 inputs and 1 output, plus
general-purpose timer.
7 Rising edge detector +
General-purpose timer
Rising edge detector with 1 input and 1 output, plus
general-purpose timer.
This detects the rising edge of an input signal and outputs the ON
signal for 2 ms.
8 Falling edge detector +
General-purpose timer
Falling edge detector with 1 input and 1 output, plus
general-purpose timer.
This detects the falling edge of an input signal and outputs the ON
signal for 2 ms.
To Next Page
