5.4 Details of Function Codes
5-264
To configure the above customizable logic, set function codes as follows. (Timer selection) and (Time
setting) require no modification unless otherwise required.
Table 5.4-191
Function Code Setting Data Setting Contents Remarks
E98 Terminal FWD (Function selection) 100 No function NONE
U00 Customizable logic (Operation
selection)
1 Enable
U01 (Input 1) 4010 FWD terminal input
signal
FWD
U03 (Logic circuit) 1 Through output +
General-purpose timer
Operation
selection
U04 (Timer selection) 3 Pulse (one-shot)
U05
Customizable logic:
Step 1
(Time setting) Any value Stage 1 run time
U06 (Input 1) 2001 Output of step 1 SO01
U08 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U09 (Timer selection) 3 Pulse (one-shot)
U10
Customizable logic:
Step 2
(Timer setting) Any value Stage 2 run time
U11 (Input 1) 2002 Output of step 2 SO02
U13 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U14 (Timer selection) 3 Pulse (one-shot)
U15
Customizable logic:
Step 3
(Time setting) Any value Stage 3 run time
U16 (Input 1) 2003 Output of step 3 SO03
U18 (Logic circuit) 8 Falling edge detector +
General-purpose timer
U19 (Timer selection) 3 Pulse (one-shot)
U20
Customizable logic:
Step 4
(Timer setting) Any value Stage 4 run time
U21 (Input 1) 2001 Output of step 1 SO01
U22 (Input 2) 2002 Output of step 2 SO02
U23
Customizable logic:
Step 5
(Logic circuit) 3 ORing +
General-purpose timer
U26 (Input 1) 2002 Output of step 2 SO02
U27 (Input 2) 2004 Output of step 4 SO04
U28
Customizable logic:
Step 6
(Logic circuit) 3 ORing +
General-purpose timer
U31 (Input 1) 2003 Output of step 3 SO03
U32 (Input 2) 2004 Output of step 4 SO04
U33
Customizable logic:
Step 7
(Logic circuit) 3 ORing +
General-purpose timer
U36 (Input 1) 2005 Output of step 5 SO05
U37 (Input 2) 2007 Output of step 7 SO07
U38
Customizable logic:
Step 8
(Logic circuit) 3 ORing +
General-purpose timer
U41 (Input 1) 4010 FWD terminal input
signal
FWD
U42 (Input 2) 2008 Output of step 8
SO08
U43
Customizable logic:
Step 9
(Logic circuit) 2 ANDing +
General-purpose timer
