5.4 Details of Function Codes
5-265
Chapter 5 Function Code
Details of
Function Codes
F codes
E codes
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U00 to U91
y codes
Function Code Setting Data Setting Contents Remarks
U71 Customizable logic
output signal 1
9 Output of step 9 SO09 FWD
command
U72 Customizable logic
output signal 2
6 Output of step 6 SO06 SS1 command
U73 Customizable logic
output signal 3
6 Output of step 6 SO06 RT1 command
U74 Customizable logic
output signal 4
7 Output of step 7 SO07 SS2 command
U75 Customizable logic
output signal 5
(Output
selection)
7 Output of step 7 SO07 RT2 command
U81 Customizable logic
output signal 1
98 Run forward, stop
command
FWD
U82 Customizable logic
output signal 2
0 Select multi-frequency
(0 to 1 step),
SS1
U83 Customizable logic
output signal 3
4 Select ACC/DEC time
(2 steps)
RT1
U84 Customizable logic
output signal 4
1 Select multi-frequency
(0 to 3 steps),
SS2
U85 Customizable logic
output signal 5
(Function
selection)
5 Select ACC/DEC time
(4 steps)
RT2
